Icom IC-440 - RX Frequency Setting (for RX Channels Only); Rx Frequency Programming; Rx Channel Setting

35
8
OTHER FUNCTIONS
8
■ RX frequency setting (for RX channels only)
The receive frequency in the RX channels can be re-pro-
grammed within 450 to 520 MHz frequency range depending
on the setting.
D RX channel setting
The RX channels does not appear on the LCD (default; “In-
hibit” setting) and you cannot select it. So the RX channels
should be set to “Enable” before programming the RX fre-
quency.
q While pushing and holding
SCAN
TAG
*
and
LOW
*
, turn power ON
to indicate all pre-programmed RX channels (including
the inhibited channels.)
w Select the desired channel with
or , then push
SCAN
TAG
*
to set the displayed channel “Enable.”
e Turn the power OFF, then ON.
• The “Enable” channels appear on the LCD, and push
CH
SQL
then
push
/ to select the desired RX channel.
D RX frequency programming
q Select the desired RX channel (‘RX-XX’). (See at left)
w Push
F
SET
(Function) to enter the function mode, then push
and hold
F
SET
(RX VFO) for 2 sec. to enter the RX VFO
mode.
• Push
LOW
*
to toggle the bandwidth between wide or narrow.
e Push or several times to select the desired fre-
quency.
• The frequency changes according to the Wide/Narrow setting.
(p. 37)
*Regardless of the assigned key function.
“Inhibit” setting “Enable” setting
RX channel
(in function mode)
RX VFO mode
Appears when
Narrow channel
spacing is set.
*
Wide channel spacing
(25 kHz steps)
Narrow channel spacing
(12.5 kHz steps)
