SET MODE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
SSB TBW (WIDE)
100 – 2900
Sets the transmission passband width to a wide
setting by changing the lower and higher cut-off fre-
quencies.
• Lower freq. : 100 (default), 200, 300 and 500 Hz
• Higher freq. :
2500, 2700, 2800 and
2900 Hz (default)
SSB TBW (MID)
300 – 2700
Sets the transmission passband width to a middle
setting by changing the lower and higher cut-off fre-
quencies.
• Lower freq. : 100, 200, 300 (default) and 500 Hz
• Higher freq. :
2500, 2700 (default), 2800
and 2900 Hz
SSB TBW (NAR) 500 – 2500
Sets the transmission passband width to a narrow
setting by changing the lower and higher cut-off fre-
quencies.
• Lower freq. : 100, 200, 300 and 500 Hz (default)
• Higher freq. :
2500 (default), 2700, 2800
and 2900 Hz
Drive Gain 50
%
Sets the drive gain level from 0% to 100% in 1%
steps. (default: 50%)
While talking into the microphone, keying down or
transmitting, rotate the main dial so that the ALC
meter reading is between 30% to 50% of the ALC
scale.
(p. ??)
The drive gain is active for all modes other than SSB
mode with speech compressor OFF.
Speech Level 50
%
Sets the voice synthesizer audio output level from
0% to 100% in 1% steps. (default: 50%)
Side Tone Level 50
%
Sets the side tone output level from 0% to 100% in
1% steps. (default: 50%)
Side Tone Level Limit ON
Turns the side tone output level limiting capability
ON and OFF. (default: ON)
When this item is set to ON, the CW side tone is
linked to the [AF] control until rotation of the [AF]
control reaches to the specified level—further rota-
tion will not increase the volume of the CW side
tones.
• ON : CW side tone level is limited with the [AF]
control.
• OFF : CW side tone level is linked to the [AF] con-
trol.
