The default settings are shown in the following table:
Input Access Control Function Default Setting
Input 1 Door Contact, Port 1 Door Contact, Port 1
Input 2 REX Input, Port 1 REX Input, Port 1
Input 3 Bond Sense, Port 1 General Purpose Input
Input 4 REN Input, Port 1 General Purpose Input
Input 5 Door Contact, Port 2 Door Contact, Port 2
Input 6 REX input, Port 2 REX Input, Port 2
Input 7 Bond Sense, Port 2 General Purpose Input
Input 8 REN Input, Port 2 General Purpose Input
