S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378 6-5
6: HMI F UNCTION
List of Button Operations after Executing a System Menu Item
Switch Press/Hold Basic operation
Press
Adds 1 to the number selected with the cursor.
Shows the item above the item selected with the cursor. If the top of the item list is displayed, nothing happens.
Press and hold Repeats the press operation.
Press
Subtracts 1 from the number selected with the cursor.
Shows the item below the item selected with the cursor. If the bottom of the item list is displayed, nothing
happens.
Press and hold Repeats the press operation.
Press Moves the cursor once to the left.
Press and hold Repeats the press operation.
Press Moves the cursor once to the right.
Press and hold Repeats the press operation.
Press Confirms the modification.
Press and hold Not valid.
Press Discards the modification.
Press and hold
While pressing the (ESC) button, press the (OK) button to discard the modification and return to the top
screen of the system menu.
Line Number:
00001 / 65535
Menu Languages:
Japanese
System menu
(Ladder monitor line setting)
Menu language selection
