Advanced Instruction Applicable SmartAXIS
Note 1: The MSG FB can be used only with SmartAXIS Pro.
Note 2: When using RAMP1 in single-pulse output mode, PULS3 and PWM3 cannot be used. When using RAMP2 in single-pulse output mode,
PULS4 and PWM4 cannot be used.
Note 3: When using RAMP1 or ARAMP1 in dual-pulse output mode, RAMP2 or ARAMP2 cannot be used.
Function blocks
Applicable SmartAXIS
FT1A-12 FT1A-24 FT1A-40 FT1A-48
Group Name SymbolACDCACDCACDCACDC
Input
Digital Input I XXXXXXXX
Special Internal Relay M XXXXXXXX
Shift Register R XXXXXXXX
Analog Input AI XXXXXXXX
Output
Digital Output Q XXXXXXXX
Internal Relay M XXXXXXXX
Logical
Operation
Logical AND ANDXXXXXXXX
Negative Logical AND NANDXXXXXXXX
Logical OR OR XXXXXXXX
Negative Logical OR NORXXXXXXXX
Exclusive Logical OR XORXXXXXXXX
Negative Exclusive Logical ORXNORXXXXXXXX
Negation NOTXXXXXXXX
Shot up SOTUXXXXXXXX
Shot down SOTDXXXXXXXX
Truth Table TRUTHXXXXXXXX
Timer
On-delay Count Up Timer TIMUXXXXXXXX
On-delay Count Down TimerTIMDXXXXXXXX
Off-delay Count Up Timer TIMOUXXXXXXXX
Off-delay Count Down TimerTIMODXXXXXXXX
On/off-delay Timer TIMCUXXXXXXXX
Single Shot Pulse SPULSXXXXXXXX
Dual Timer DTIMXXXXXXXX
Random Pulse Output RPULSXXXXXXXX
Counter
Adding Counter CNTXXXXXXXX
Up/Down Selection Reversible
Counter
CUDXXXXXXXX
Hour Meter HOURXXXXXXXX
Shift RegisterShift Register SFRXXXXXXXX
Data
Comparison
Data Comparison CMPXXXXXXXX
Schmitt Trigger STTGXXXXXXXX
Range Comparison RCMPXXXXXXXX
Data
Conversion
Alternate Output ALTXXXXXXXX
Week
Programmer
Weekly Timer WEEKXXXXXXXX
Yearly Timer YEARXXXXXXXX
Interface Message MSG
X
(Note 1)
X
(Note 1)
X
(Note 1)
X
(Note 1)
X
(Note 1)
X
(Note 1)
X
(Note 1)
X
(Note 1)
Pulse
Pulse Output PULS
X
(Note 2)
XX
Pulse Width Modulation PWM
X
(Note 2)
XX
Ramp Pulse Output RAMP
X
(Note 3)
X
(Note 3)
X
(Note 3)
Zero Return ZRN XXX
Advanced Ramp ARMP
X
(Note 3)
X
(Note 3)
X
(Note 3)
Data Logging
Data Log DLOG XXXX
Data Trace TRACE XXXX
Script Script SCRPTXXXXXXXX
Special
High-speed Counter HSC X X X X
RS Flip-flop RSFFXXXXXXXX
