S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378 8-15
8: I NSTRUCTIONS /F UNCTION B LOCKS R EFERENCE
Script FB
This section describes the script FB of the SmartAXIS and its functions.
Special FB
This section describes the special FB of the SmartAXIS and its functions.
Symbol Name and Diagram Function
Output
inversion
FBD manual
page
SCRPT
Script
Enables you to program complicated processing with
the script language that supports conditional
branching, logical operations, arithmetic operations,
and functions.
– 17-1
SCRPT
EN OUT
Symbol Name and Diagram Function
Output
inversion
FBD manual
page
HSC
High-speed Counter
Operates the high-speed counter configured in the
function area settings. Turns on/off the high-speed
counter gate input/reset input.
X 18-1
RSFF
RS Flip-flop
With the rise of the set input, the output turns on
and is maintained. When the reset input turns on,
the output is reset.
X 18-3
HSC
GT OUT
RST
CLR
RSFF
SET OUT
RST
