8: I NSTRUCTIONS /F UNCTION B LOCKS R EFERENCE
Applicable Data Types
Function blocks
Data type
WI DL F
Group Name Symbol Word Integer Double word Long Float
Input
Digital Input I 
Special Internal Relay M 
Shift Register R 
Analog Input AI  X 
Output
Digital Output Q 
Internal Relay M 
Logical
Operation
Logical AND AND 
Negative Logical AND NAND 
Logical OR OR 
Negative Logical OR NOR 
Exclusive Logical OR XOR 
Negative Exclusive Logical OR XNOR 
Negation NOT 
Shot up SOTU 
Shot down SOTD 
Truth Table TRUTH 
Timer
On-delay Count Up Timer TIMU X 
On-delay Count Down Timer TIMD X 
Off-delay Count Up Timer TIMOU X 
Off-delay Count Down Timer TIMOD X 
On/off-delay Timer TIMCU X 
Single Shot Pulse SPULS X 
Dual Timer DTIM X 
Random Pulse Output RPULS X 
Counter
Adding Counter CNT X  X 
Up/Down Selection Reversible
Counter
CUD X  X 
Hour Meter HOUR X 
Shift Register Shift Register SFR 
Data
Comparison
Data Comparison CMP X X X X 
Schmitt Trigger STTG X X X X 
Range Comparison RCMPXXXX
Data
Conversion
Alternate Output ALT 
Week
Programmer
Weekly Timer WEEK 
Yearly Timer YEAR 
InterfaceMessage MSGXXXXX
Pulse
Pulse Output PULS 
Pulse Width Modulation PWM 
Ramp Pulse Output RAMP 
Zero Return ZRN 
Advanced Ramp ARMP 
Data Logging
Data Log DLOGXXXXX
Data Trace TRACEXXXXX
Script Script SCRPT X X X X X
Special
High-speed Counter HSC X  X 
RS Flip-flop RSFF 
