S
MART
AXIS P
RO
/L
ITE
U
SER
'
S
M
ANUAL
FT9Y-B1378 9-7
9: M
AINTENANCE
C
OMMUNICATION
5. Set the parameters to match the communication settings of the PC or operator interface.
Notes:
• Settings not in parentheses are the default values.
• The number of clients that can be connected to the SmartAXIS simultaneously is one client per connection. If connections 1 to 3 are all set to
the maintenance communication server, three clients can connect to the SmartAXIS at the same time.
6. Click OK.
This completes maintenance communications settings.
Download User Program and Confirm IP Addresses via USB Port
Before starting Ethernet communication, configure the function area settings and download the user program to the SmartAXIS via
USB.
7. Connect the PC and the SmartAXIS using a USB cable.
8. From the WindLDR menu bar, select Online > Transfer > Download.
The Download dialog box appears.
Local Host Port No.: 2101 (The port number that the SmartAXIS uses for the maintenance communication server)
Receive Timeout (ms): 2000 (100 to 25500ms)
Allow Access by IP Address: Disabled (Enabling this option makes it possible to prevent access from devices having any IP addresses
other than the one entered.)
To Next Page
