12: R
EMOTE
I/O
12-10 S
MART
AXIS P
RO
/L
ITE
U
SER
'
S
M
ANUAL
FT9Y-B1378
Remote I/O Slave Operation and Restrictions
The remote I/O slave outputs conform to the remote I/O master outputs. Therefore, the following restrictions are applied when
the SmartAXIS operates as a remote I/O slave.
Special internal relays
All Outputs OFF (M8002) Cannot be used.
Maintain Outputs While CPU Stopped
(M8025)
Cannot be used.
Communication settings
Serial communication port
The communication mode is always "Maintenance Communication". The
communication settings are fixed as the following settings.
Baud rate: 115,200 bps
Data length: 7 bits
Parity: Even
Stop bits: 1 bit
Ethernet Communication Cannot be used except for remote I/O communication.
Maintenance
Communication
Access to devices
Output relay (Q) on/off state cannot be changed.
Other devices can be read and written to normally.
Forced I/O function Cannot be used.
Data File Manager Cannot be used.
