IDEC FT1A Series User Manual

S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378 14-15
14: T ROUBLESHOOTING
Troubleshooting Diagram 7
Does the monitored input
turn on and off?
NO
YES
NO
YES
YES
Call IDEC for assistance.
Monitor the designated stop or reset
input using WindLDR on a computer.
NO
Is the designated stop or
reset input on?
Is M8000 off?
Turn on the designated input.
The input circuit in the SmartAXIS is
damaged.
Replace the SmartAXIS.
Is stop or
reset input designated in
the WindLDR Function Area
Settings?
Monitor the start control special internal
relay M8000 using WindLDR on a
computer.
YES
Turn off the start control special internal
relay M8000 using WindLDR on a
computer.
NO
Cannot stop or reset operation.
Note: To monitor M8000, from the WindLDR menu bar, select
Online > Monitor > Monitor, then Online > Custom > New
Custom Monitor. Enter M8000 in the Device box in the Custom
Monitor dialog box.
Note: To turn off M8000, enter 0 in the Current Value box in the
Custom Monitor dialog box.

IDEC FT1A Series Specifications

General

Programming Software	WindLDR
Type	Programmable Logic Controller (PLC)
Display	LCD (varies by model)
Communication Ports	RS232C/RS485 (built-in), USB (programming), Ethernet (optional)
Dimensions	Varies by model
Weight	Varies by model
Model	FT1A Series
