3.1 LCD Specifications
3.1.1 LCD Overview
The DM series LCD monitors use the following LCD panels.
 DM-150: AUO G150XG01 V3
 DM-170: AUO G170EG01 V1
 DM-190: AUO G190EG01 V1
Detailed specifications for the LCD screens are listed in the following sections.
3.1.2 DM-150 LCD Specifications
Table 3-1 lists the DM-150 LCD specifications.
Ite m s DM-150
Size 15”
Brand AUO
Model G150XG01 V3
Backlight LED
Brightness (cd/m2) 400
Resolution 1024 x 768
Screen Scale 4:3
Life Time 50000H
Contrast Ratio 700:1
View Angle (H/V) 160/140
Interface 1ch LVDS
Operating Temperature -30~85°C
Active Area (mm) 304.1 x 228.1
Pixel Pitch (mm) 0.297
Display Mode Normal White
Number of Colors 16.2M
Supply Voltage (V) 3.3
Table 3-1: DM-150 LCD Specifications
