IEI Technology DM-150GS/R-R30 User Manual

DM Series Monitor
Page 21
3.1.3 DM-170 LCD Specifications
Table 3-2 lists the DM-170 LCD specifications.
Ite m s DM-170
Size 17”
Brand AUO
Model G170EG01 V1
Backlight LED
Brightness (cd/m2) 350
Resolution 1280 x 1024
Screen Scale 4:3
Life Time 50000H
Contrast Ratio 800:1
View Angle (H/V) 170/160
Interface 2ch LVDS
Operating Temperature -30~85°C
Active Area (mm) 337.9 x 270.3
Pixel Pitch (mm) 0.264
Display Mode Normal White
Number of Colors 16.7M
Supply Voltage (V) 5
Table 3-2: DM-170 LCD Specifications
3.1.4 DM-190 LCD Specifications
Table 3-3 lists the DM-190 LCD specifications.
Ite m s DM-190
Size 19”
Brand AUO
Model G190EG01 V1
Backlight LED
