IEI Technology DM-150GS/R-R30 User Manual

DM Series Monitor
Page 31
5.4 Connectors
Table 5-1 lists the rear panel connectors for the DM series LCD monitors.
Connectors DM-150 DM-170 DM-190
VGA Yes Yes Yes
DVI-D Yes Yes Yes
Power (12V Jack) Yes Yes Yes
RS-232 for Touch Panel Yes Yes Yes
USB for Touch Panel Yes Yes Yes
Power (9~36V Terminal Block)
(Optional for M model)
Yes Yes Yes
Table 5-1: Rear Panel Connectors
5.4.1 Rear Panel Connectors Overview
Figure 5-1: Monitor Rear Panel Connections
