DM Series Monitor

Page 45

NOTE:

In the diagram below the bracket is already installed on the wall.

Figure 5-20: Wall Mounting the Monitor

5.5.4 Monitor Stand Installation

The DM series LCD monitor has Video Electronics Standards Association (VESA)

standard mounting holes tapped into the rear panel. The standard holes are M4 set at

100m x 100mm apart (Figure 5-21).
