IEI Technology DM-150GS/R-R30 User Manual

DM Series Monitor
Page 34
Figure 5-5: RS-232 Touch Panel Connector
5.4.6 USB for Touch Panel Connector
Use the rear panel standard USB touch panel connector to connect the monitor to the
system graphics interface.
PIN DESCRIPTION PIN DESCRIPTION
1 VCC 5 VCC
2 Data- 6 Data-
3 Data+ 7 Data+
4 GND 8 GND
Table 5-5: USB Touch Panel Connector Pinouts
Figure 5-6: USB Touch Panel Connector
5.4.7 Optional Terminal Block
Use the rear panel 3-pin terminal block DC power connector to connect the monitor to a
DC power source.
