IEI Technology DM-150GS/R-R30 User Manual

DM Series Monitor
Page 46
Figure 5-21: VESA Mounting Holes
The monitor stand mounting plate has a matching VESA hole pattern. To mount the DM
series LCD monitor onto a stand, please follow the steps below.
Step 1: Line up the threaded holes on the monitor rear panel with the screw holes on the
monitor stand mounting plate.
Step 2: Secure the monitor to the stand with the supplied retention screws (Figure
5-22).
Figure 5-22: Monitor Stand Mounting
