Page 39
5.5.2.1 Standard Cabinet and Rack Installation
The standard cabinet/rack mounting procedure applies to the following DM series LCD
monitors:
 DM-170
 DM-150
To mount the DM series LCD monitor into a cabinet/rack, please follow the steps below.
Step 1: The back of the metal frame surrounding the DM series LCD monitor has
several retention screw holes for a cabinet/rack installation bracket.
NOTE:
When purchasing a cabinet/rack
installation bracket, make sure it is
compatible with both the monitor and the cabinet/rack into which the
monitor is installed.
Step 2: Slide the monitor through the cabinet/rack bracket until the rear side of the
monitor frame is flush against the front of the bracket.
Step 3: Make sure the retention screw holes at the rear of the monitor frame are aligned
with the retention screw holes in the cabinet/rack bracket.
Step 4: Secure the cabinet/rack bracket to the monitor by inserting and tightening the
retention screws (Figure 5-13).
