Index S-Idx Name Type Default Description
1A00 0 Mapping Transmit PDO 1 u32 ro 0x04 number of implemented
application objects
1 Index in
object directory
u32 ro 0xA100 01 in A100 SIdx 01, 1
st
word
transmitted data TX PDO 1
2 Index in
object directory
u32 ro 0xA100 02 in A100 SIdx 02, 2
nd
word
transmitted data TX PDO 1
3 Index in
object directory
u32 ro 0xA100 03 in A100 SIdx 03, 3
rd
word
transmitted data TX PDO 1
4 Index in
object directory
u32 ro 0xA100 04 in A100 SIdx 04, 4
th
word
transmitted data TX PDO 1
1A01 0 Mapping Transmit PDO 2 u32 ro 0x04 number of implemented
application objects
1 Index in
object directory
u32 ro 0xA101 01 in A101 SIdx 01, 1
st
word
transmitted data TX PDO 2
2 Index in
object directory
u32 ro 0xA101 02 in A101 SIdx 02, 2
nd
word
transmitted data TX PDO 2
3 Index in
object directory
u32 ro 0xA101 03 in A101 SIdx 03, 3
rd
word
transmitted data TX PDO 2
4 Index in
object directory
u32 ro 0xA101 04 in A101 SIdx 04, 4
th
word
transmitted data TX PDO 2
1A02 0 Mapping Transmit PDO 3 u32 ro 0x04 number of implemented
application objects
1 Index in
object directory
u32 ro 0xA102 01 in A102 SIdx 01, 1
st
word
transmitted data TX PDO 3
2 Index in
object directory
u32 ro 0xA102 02 in A102 SIdx 02, 2
nd
word
transmitted data TX PDO 3
3 Index in
object directory
u32 ro 0xA102 03 in A102 SIdx 03, 3
rd
word
transmitted data TX PDO 3
4 Index in
object directory
u32 ro 0xA102 04 in A102 SIdx 04, 4
th
word
transmitted data TX PDO 3
1A03 0 Mapping Transmit PDO 4 u32 ro 0x04 number of implemented
application objects
1 Index in
object directory
u32 ro 0xA103 01 in A103 SIdx 01, 1
st
word
transmitted data TX PDO 4
2 Index in
object directory
u32 ro 0xA103 02 in A103 SIdx 02, 2
nd
word
transmitted data TX PDO 4
3 Index in
object directory
u32 ro 0xA103 03 in A103 SIdx 03, 3
rd
word
transmitted data TX PDO 4
4 Index in
object directory
u32 ro 0xA103 04 in A103 SIdx 04, 4
th
word
transmitted data TX PDO 4
1A04 0 Mapping Transmit PDO 4 u32 ro 0x04 number of implemented
application objects
1 Index in
object directory
u32 ro 0xA104 01 in A104 SIdx 01, 1
st
word
transmitted data TX PDO 5
2 Index in
object directory
u32 ro 0xA104 02 in A104 SIdx 02, 2
nd
word
transmitted data TX PDO 5
3 Index in
object directory
u32 ro 0xA104 03 in A104 SIdx 03, 3
rd
word
transmitted data TX PDO 5
4 Index in
object directory
u32 ro 0xA104 04 in A104 SIdx 04, 4
th
word
transmitted data TX PDO 5
