Index S-Idx Name Type Default Description
1A05 0 Mapping Transmit PDO 6 u32 ro 0x04 number of implemented
application objects
1 Index in
object directory
u32 ro 0xA105 01 in A105 SIdx 01. 1
st
word
transmitted data TX PDO 6
2 Index in
object directory
u32 ro 0xA105 02 in A105 SIdx 02, 2
nd
word
transmitted data TX PDO 6
3 Index in
object directory
u32 ro 0xA105 03 in A105 SIdx 03, 3
rd
word
transmitted data TX PDO 6
4 Index in
object directory
u32 ro 0xA105 04 in A105 SIdx 04,4
th
word
transmitted data TX PDO 6
1A06 0 Mapping Transmit PDO 7 u32 ro 0x04 number of implemented
application objects
1 Index in
object directory
u32 ro 0xA106 01 in A106 SIdx 01,1
st
word
transmitted data TX PDO 7
2 Index in
object directory
u32 ro 0xA106 02 in A106 SIdx 02,2
nd
word
transmitted data TX PDO 7
3 Index in
object directory
u32 ro 0xA106 03 in A106 SIdx 03,3
rd
word
transmitted data TX PDO 7
4 Index in
object directory
u32 ro 0xA106 04 in A106 SIdx 04,4
th
word
transmitted data TX PDO 7
1A07 0 Mapping Transmit PDO 8 u32 ro 0x04 number of implemented
application objects
1 Index in
object directory
u32 ro 0xA107 01 in A107 SIdx 01,1
st
word
transmitted data TX PDO 8
2 Index in
object directory
u32 ro 0xA107 02 in A107 SIdx 02,2
nd
word
transmitted data TX PDO 8
3 Index in
object directory
u32 ro 0xA107 03 in A107 SIdx 03, 3
rd
word
transmitted data TX PDO 8
4 Index in
object directory
u32 ro 0xA107 04 in A107 SIdx 04,4
th
word
transmitted data TX PDO 8
