IFM O1D300 - Electrical connection

14
6 Electrical connection
The unit must be connected by a qualified electrician�
► The national and international regulations for the installation of electrical
equipment must be adhered to�
► Voltage supply according to EN 50178, SELV, PELV�
► Disconnect power�
► Connect the unit as follows:
4
21
3
5
EPS Source
Product Scale Drawing
Frame Size: 36 mm x 75 mm
AN_i_1707_G Original Scale Drawing (MTD)
L
+
L
5
1
4
3
2
IN
L
+
L
5
1
4
3
2
IN
2: Out 2
4: Out 1
2: Out 2
4: Out 1
L
+
L
5
1
4
3
2
IN
L
+
L
5
1
4
3
2
IN
2: Out 2
4: Out 1
2: Out 2
4: Out 1
Core colours of ifm sockets:
1 = BN (brown), 2 = WH (white), 3 = BU (blue), 4 = BK (black), 5 = GR (grey)�
