IFM O1D300 - Page 18

18
The reset point for window and hysteresis function OUT1
[rP1] must be set separately from [SP1]� [rP1] < [SP1]
Hysteresis function
Lower limit value at which the output with selected hysteresis function
changes its switching status (medium nearer / farther than distance set)�
• [rP1] is the reset point if [OU1] = [Hno]�
• [rP1] is the set point if [OU1] = [Hnc]�
→ 10.3.4 Setting of the switch points for hysteresis function OUT1
Window function
[rP1] is the lower limit value at which the output with selected window
function changes its switching status if [OU1] = [Fno] or [Fnc]�
→ 10.3.5 Setting of the switch points for window function OUT1
Configuration for output 2
4 switching functions and 2 analogue signals can be selected:
[Hno], [Hnc], [Fno], [Fnc], [I], [U] → 10.3.6 Configure OUT2
Switch point for window and hysteresis function OUT2
Hysteresis function
Upper limit value at which the output with selected hysteresis function
changes its switching status (medium nearer / farther than distance set)�
• [SP2] is the set point if [OU2] = [Hno]�
• [SP2] is the reset point if [OU2] = [Hnc]�
→ 10.3.7 Setting of the switch points for hysteresis function OUT2
Window function
[SP2] is the upper limit value at which the output with selected window
function changes its switching status if [OU2] = [Fno] or [Fnc]�
→ 10.3.8 Setting of the switch points for window function OUT2
The reset point for window and hysteresis function OUT2
[rP2] must be set separately from [SP1]� [rP2] < [SP1]
Hysteresis function
Lower limit value at which the output with selected hysteresis function
changes its switching status (medium nearer / farther than distance set)�
• [rP2] is the reset point if [OU2] = [Hno]�
• [rP2] is the set point if [OU2] = [Hnc]�
→ 10.3.7 Setting of the switch points for hysteresis function OUT2
Window function
[rP2] is the lower limit value at which the output with selected window
function changes its switching status if [OU2] = [Fno] or [Fnc]�
→ 10.3.8 Setting of the switch points for window function OUT2
Analogue start point
Measured value at which 4 mA / 0 V are provided�
[ASP] is only active if [OU2] = [I] or [U]�
→ 10.3.9 Scaling of the measuring range (analogue output)
