IKONIX apt 400XAC Series User Manual

23
Accuracy
± (1% of reading + 5counts) at 40.0-70.0Hz
± (1.5% of reading + 10counts) at 70.1 - 500Hz
± (1.5% of reading + 10counts) at 501 - 1000Hz and CF<1.5
Power (*5)
Range
L
0.0W~120.0W
0.0W~240.0W
H
100W~1300W
200W~2600W
Resolution
L
0.1W
H
1W
Accuracy
L
± (2% of reading +15 counts) at 40.0-500Hz and PF>=0.2
± (2% of reading +30 counts) at 501-1000Hz and PF>=0.5
H
± (2% of reading +5 counts) at 40.0-500Hz and PF>=0.2
± (2% of reading +15 counts) at 501-1000Hz and PF>=0.5
Power Factor
Range
0 - 1.000
Resolution
0.001
Calculated Formula
W / VA
Power Apparent
(VA)
Range
(*15)
L
0.0VA~120.0VA
0.0VA~240.0VA
H
100VA~1300VA
200VA~2600VA
Resolution
L
0.1VA
H
1VA
Calculated Formula
V×A
Power Reactive
(Q) (*13)
Range
(*15)
L
0.0VAR~±120.0VAR
0.0VAR~±240.0VAR
H
0VAR~±1300VAR
0VAR~±2600VAR
Resolution
L
0.1VAR
H
1VAR
Calculated Formula
(*14)
Crest Factor
Range
0 - 10.00
Resolution
0.01
Calculate Formula
Ap / A
Poly-phase
mode(1Ø3W) for
L1-L2
measurement
(Option)
Frequency
Range
0.1-1000Hz
Resolution
0.1Hz
Accuracy
±0.1Hz (501-1000Hz Accuracy ±0.2Hz)
Voltage
Range
0.0-840V
