iLumin SC-RP User Manual

P35
d. Use the or buttons to highlight the Output
number and repeat step b. for each Output and then
press the
ENT
button to save and exit.
Step 17: Congure DMX
Objective: Congure DMX to allow DMX consoles to control the SCRP Switched Relay Controller Outputs.
To map Outputs to DMX channels
DMX Output Mapping allows you assign the SCRP Out-
puts to any DMX control channels between 1 and 512.
This can either be done sequentially from a particular
DMX channel or you can assign each Output individually.
1. From the Conguration menu, highlight the ‘DMX Op-
tions’ entry and press the
ENT
button. The following
options will be displayed:
2. Ensure that the ‘Output Mapping’ option is highlighted
and press the
ENT
button. The display will show two
options:
DMX Options
Output Mapping
DMX Output Mapping
Sequentially From 1
Individually
Sequential mapping
a. Highlight that the ‘Sequentially From...’ option is
highlighted and press the
ENT
button.
DMXOutputMapping
MapOutput1to
DMXChannel
1
b. Enter the DMX channel number (1 - 512) to which
Output 1 should be assigned and press the
ENT
button.
All Outputs within the SCRP will be assigned to
DMX channels in succession from your initial
number and then you will be returned to the DMX
Output Mapping menu.
Individual mapping
a. Highlight the ‘Individually’ option and press the
ENT
button.
DMXOutputMapping
Output1 DMX1
Output2 DMX2
Output3 DMX3
Output4 DMX4
w.p.
w.p.
w.p.
w.p.
Note: The default for each Output is set to “w.p.”- ‘DMX
When Present’. This means that DMX controls the output
when present, otherwise CAN does.
b. To change from the default of ‘DMX when Present’,
press the
button to to toggle thru the control
hierarchy options:
1. ‘CAN Only’, which means DMX does not affect
the output.
2. ‘DMX only’, which means that CAN does not
affect the output. (see below)
c. Press the
ENT
button to save and exit.
DMXOutputMapping
Output1 DMX1
Output2 DMX2
Output3 DMX3
Output4 DMX4
only
w.p.
w.p.
w.p.
DMXOutputMapping
Output1 CAN Only
Output2 DMX2
Output3 DMX3
Output4 DMX4
w.p.
w.p.
w.p.
