Introduction
Welcome
The iLumin Switched Relay Controller from Cooper Lighting Solutions has been designed to provide flexibility in
both installation and operation. Each model in the product family can accept a variety of industry standard
control options including iCANbus, DMX, Ethernet, and RS485. Similarly, every model can drive a wide range of
lighting loads, from incandescents to dimmable fluorescents, from non-dim apparatus to DALI (Canada and Mexico
only) digital modules. All Switched Relay Controller models feature a fold-out control panel which provides access to
an intuitive configura-tion menu to allow quick and flexible configuration.
This guide provides full information about programming the Switched Relay Controller using the control panel. For
details about mounting and connecting iLumin Switched Relay Controller products, please refer to the accompanying
Installation Guide 9850-000016 (9850-000017) for the SCRPB.
Product Overview
Each model is specified using a part number in the following format:
For SC-RP (Relay Panels)
Ordering Examples:
Product
SC
Source
Number of
Circuits
18
36
48
Voltage
M Mixed
Source Controller Type
RP Relay Panel
Phase
MP Multi Phase
Panel Feed
FT Feed Through
Branch Breaker Rating (Amps)
20 20 Amp
SC M - 18 - RP - MP - FT - 20 - S - 12 - 3 - HF1
Enclosure
S Surface
Number of Single Pole Relays
18 = 0-18
36 = 0-36
48 = 0-48
Number of Two Pole Relays (two pole relays count as 2 single pole relays)
1 to 24
Interior Options
Blank 0, 0-10V Dimming Channels
HF1 12, 0-10V Dimming Channels
HF2 24, 0-10V Dimming Channels
1. SC-M-18-RP-MP-FT-20-S-12-3-HF2
18 circuit surface mount feed through panel with 12 single pole relays, 3 two pole relays, 24 0-10V
dimming channels
2. SC-M-36-RP-MP-FT-20-S-18-0-0
36 circuit surface mount feed through panel with 36 single pole relays, no two pole relays, no 0-10V
dimming channels
