2. Use the or buttons to navigate the Outputs.
3. Press the
ENT
button to edit details for the current
Output number:
To congure the behavior of an Output
1. From the Conguration menu, highlight the ‘Congure
Outputs’ option and press the
ENT
button. The display
will show a summary of the settings for the rst output:
Configure Output 1
Standard Type
Set Area andZone
HF Curve
(0-10V)
HF curve: Switched
<>for more
Output 1
Max 100%Min 0%
4. Highlight the ‘Standard Type‘ option and press the
ENT
button. The list of standard lighting loads will be
displayed:
Load Type Power Curve HF Curve Min Max
Non-dim source Switched Switched 0 100
0-10V driver/ballast Switched 0-10V 0 100
1-10V driver/ballast Switched 1-10V 0 100
Operation at Min
Output 1StandardType
Non-Dim Source
1-10V Driver/Ballast
0-10V Driver/Ballast
5. Highlight the type that most closely matches the load
connected to the Output and press the
ENT
button.
Once selected, all basic parameters will be set for the
load (as summarized right) and you will be returned to
the ‘Congure Output x’ menu. Other options can be
changed here, however, for most standard installations
no further changes are required. See the next two
pages for details about all of the available options in
the Congure Output menu.
Note: The ‘Set Area and Zone’ option allows you to
assign the chosen Output to a particular Area and
Zone - these operations can also be performed later
using the iCANsoft application.
6. Press the
ESC
button to return to the summary of set-
tings for the Output. From here, either:
• Select another Output number using the or
buttons, or
• Press the
ESC
button to return to the Conguration
menu.
When all Outputs are congured, go to Step 7
HF curve: 0-10V
<>for more
Output1
Max 100%Min 0%
Power curve: Square
Area 32
Zone 256
<>for more
Output1
Output number
- use &
to change
HF (low voltage) curve
settings
Existing Area
and
Zone settings
Existing
Minimum
and Maximum
power
dimming limits
Step 6: Congure Output behaviors
Objective: To congure each Output to properly control the connected load type.
Off
Off
Off
