P9
Menu Navigation
Within the control panel menu system, use the following
buttons to navigate:
Press to select an item or to save
changes.
ENT
Press to enter an option or select an item.
ESC
Press to escape from an option and return to the
previous level.
The Asterisk will be used on some Scenes to per-
form special functions.
The menu system is comprised of two main sections:
• The Operation menu
Contains functions for users to operate the system. Func-
tions include: Output override, Timeclock functions, Power
data figures, etc.
• The Conguration menu
Provides functions primarily used during initial commission-
ing and subsequent fine tuning of the installation by engi-
neers.
To prevent unauthorized access, use the Password Man-
ager to congure four-digit passwords for the Operation
and Conguration menus.
Please see the next pages for more detailed information
about the Operation and Conguration menus.
See page 12 for the list of commissioning steps
Accessing the operation menu
During normal service of the Switched Relay Controller,
the control panel screen shows only the time, date and
device number.
To access the operation menu
1. Press the button to display the Select Access Level
menu.
2. With the ‘Operation’ option highlighted, press the but-
ton.
3. If requested, enter the four digit operation password
and press the button. Note: When the unit is supplied,
there is initially no password - see the section ‘Chang-
ing the operation menu password’ to set one.
4. If the password is accepted, the main Operation menu
will be displayed.
