For SC-RPB (Relay Panels with Circuit Breakers)
Product
SC
Source
Number of
Circuits
18
30
42
Voltage
120V
277V
347V
Source Controller Type
RPB Relay Panel with Breakers
Phase
1P Single Phase
3P Three Phase
Panel Feed
ML Main Lugs
Branch Breaker Rating (Amps)
20 20 Amp (default)
SC 120V - 18 - RPB - 3P - ML - 20 - S - 12 - 3 - HF1
Enclosure/Interior Options
S Surface
S-PW Surface Prewired
Number of Single Pole Relays
18 = 0-18 Relays
30 = 0-36 Relays
42 = 0-48 Relays
Number of Two Pole Relays (two pole relays count as 2 single pole relays)
0 to 24
Interior Options
0 0, 0-10V Dimming Channels
HF1 12, 0-10V Dimming Channels
HF2 24, 0-10V Dimming Channels
Catalog# Discription
SC120V-18-RPB-1P-ML-20-S-18-0-0 Switched Relay Controller with 18 - 20A 120V Breakers, 1P - 250A Main Lugs and 18 Latching Relays
18 Relay SC120V-18-RPB-3P-ML-20-S-18-0-0 Switched Relay Controller with 18 - 20A 120V Breakers, 1P - 250A Main Lugs and 18 Latching Relays
SC277V-18-RPB-1P-ML-20-S-18-0-0 Switched Relay Controller with 18 - 20A 277V Breakers, 1P - 250A Main Lugs and 18 Latching Relays
SC277V-18-RPB-3P-ML-20-S-18-0-0 Switched Relay Controller with 18 - 20A 277V Breakers, 1P - 250A Main Lugs and 18 Latching Relays
SC347V-18-RPB-3P-ML-20-S-18-0-0 Switched Relay Controller with 18 - 20A 347V Breakers, 1P - 400A Main Lugs and 18 Latching Relays
Catalog# Discription
SC120V-30-RPB-3P-ML-20-S-36-0-0 Switched Relay Controller with 30 - 20A 120V Breakers, 3P - 250A Main Lugs and 36 Latching Relays
36 Relay SC277V-30-RPB-3P-ML-20-S-36-0-0 Switched Relay Controller with 30 - 20A 277V Breakers, 3P - 250A Main Lugs and 36 Latching Relays
SC347V-30-RPB-3P-ML-20-S-36-0-0 Switched Relay Controller with 30 - 20A 347V Breakers, 3P - 400A Main Lugs and 36 Latching Relays
Catalog# Discription
SC120V-42-RPB-3P-ML-20-S-48-0-0 Switched Relay Controller with 42 - 20A 120V Breakers, 3P - 400A Main Lugs and 48 Latching Relays
48 Relay SC277V-42-RPB-3P-ML-20-S-48-0-0 Switched Relay Controller with 42 - 20A 277V Breakers, 3P - 400A Main Lugs and 48 Latching Relays
SC347V-42-RPB-3P-ML-20-S-48-0-0 Switched Relay Controller with 42 - 20A 347V Breakers, 3P - 400A Main Lugs and 48 Latching Relays
