Operation manual EPM-XP
Software Release l.0.5.17 2019-01-29
Page 16 of 50
6.4 Monitoring of combustion data
6.4.1 Screen page “Cylinder pressure curve”
6.4.1.1 Indication of cylinder pressure (single) versus volume
Indication of selected load
and max. measured cylinder
(max. 20 of selected load).
Screen page
Pmax diagram
Screen page
Engine Report
Screen page
Pmax Balance
Indication of all measured
curves overlapped or single
cylinder selection and p/v
diagram
Screen page Pcomp Balance
Only on two strokes
Screen page
IMEP
Screen page
IMEP Balance
Screen page
Engine data and
manual input of
scav.air pressure
Indication of Pmax or
Pcomp10 cycles
Remark: Pcomp 10 cycles can
not displayed on 4 stroke
application
Screen page
remarks
Arrow function to shift
curves with 0.1 resolution.
Screen page
Performance
Not displayed
“Optimize“ function
Only for 2-strokes
