6.5.1.7 Save a reference curve
After selecting a cylinder as a reference curve press button “Save Ref-File”.
6.5.1.8 Open reference curve for to optimize TDC position of other cylinder
6.5.1.9 Open reference curves of selected load for MAN B&W MC-C engines
Please “Open REF File” and list of reference curves on selected load for MAN B&W MC-C engines will appear
6.5.1.10 Compare actual measurements with reference curve
Note: The reference file can only be compared with measurements at same load condition.
Shift curve into reference curve
by using function „AutoShift“
