Operation manual EPM-XP
Software Release l.0.5.17 2019-01-29
Page 18 of 50
6.4.1.4 Cross On function
Cross On: Push with mouse “Cross On” button and move mouse to the position of curve
Cross Off: Push with mouse “Cross Off” button
6.4.1.5 Save as ASCII
Press “ASCII-File” to save all measurement data from all loads to Excel (*.csv) files.
The software opened a window to store data to (*.csv) files.
Indication of pressure
[bar] and crank angle
position [CA]
