Up to 160 measurement data sets can be stored in the
EPM-XP. The stored data can be downloaded via USB-
interface to a personal computer for evaluation.
The scope of supply includes software for Windows which
allows additional evaluation and visualization of the
collected data.
4.2 Measure functions
Pmaxmean: average maximum pressure
Pcomp: Compression pressure (only on two stroke
application)
RPM: engine speed
A complete individual pressure curve (or an average over
the selected number of cycles) will be stored in the
EPM-XP memory with each measurement.
4.3 Functional description
The cylinder pressure will be measured with the EPM-XP
unit incl. high temperature pressure sensor at indicator cock
on marine diesel engines.
Memory : 160 data sets
Application 2 – stroke: 40 – 300 RPM
Application 4 – stroke: 200 – 1500 RPM
The battery must be re-charged after approximately one
hour of continuous operation.
