Operation manual EPM-XP
Software Release l.0.5.17 2019-01-29
Page 49 of 50
12 Nomenclature
RPM Engine speed
Pmax Mean of maximum pressure [bar]
Cycles Number of working cycles
Dp/Ca Maximum rise of pressure curve [bar/CA]
Pcomp Compression pressure [bar]
IMEP Indicated Mean Effective Pressure [bar]
IPOWER Indicated Power [kW]
13 Technical data
Measuring range 0…300 bar
Accuracy (EPM-XP incl HTT cylinder pressure sensor)
< 0,5 % full scale
Max. temperature at measuring cell 300 °C
Storing capacity 160 measurements / engine
Interface USB
Battery E-block re-chargeable type ANSMANN
250 mAh NiMh
Dimension 180 x 24 x 52
Weight (incl. battery) 350 g
14 Warranty
The warranty period is 12 month after delivery according to the general terms and conditions of the electric
industry of Germany.
15 IMES Sales and service organization
https://www.imes.de/sales-team.html
