IMES EPM-XP - Indication of IPOWER and IMEP on Screen Page Engine Report; Auto Shift Function; Select a Curve as Reference Curve

Operation manual EPM-XP
Software Release l.0.5.17 2019-01-29
Page 31 of 50
6.5.1.4 Indication of IPOWER and IMEP on screen page “Engine report”
6.5.1.5 “Auto shift” function
The “Auto shift” function allows user to shift automatic curves into selected reference curves.
6.5.1.6 Select a curve as reference curve
Indication of IMEP
and IPOWER
Total IPOWER Engine
Mean values of
cylinder
Use „Derivative curve
function“
Zoom
Lowest position of derivative
curve should be between 0.1
and 2 °CA depending on load
