IMES EPM-XP - Connection of EPM-XP to Pressure Calibrator

Operation manual EPM-XP
Software Release l.0.5.17 2019-01-29
Page 42 of 50
8.1 Connection of EPM-XP to pressure calibrator
Connect EPM-XP unit with thompson adaptor to pressure calibrator (fig.18).
Please check possible leakage at adaptor by generating pressure.
Fig.18: Connection of EPM-XP to pressure calibrator
Note: The pictured pressure calibrator is an example to generate pressure. At your workshop you can use
your standard pressure calibrator.
Indication of
pressure on EPM-XP
Adjusted pressure at
calibrator
