Page 28 of 50
6.4.10.2 Indication of effective Power in screen page “Engine report”
Indication of effective Power (shaft power)
6.4.11 Pipe oscillation filter
On some engines the pressure signal at low load is superposed with pipe oscillation. Pipe oscillation disturbes
the software algorithm for Pcomp detection and TDC positioning.
Remark: Pipe oscillation is a physical phenomenom that has nothing to do with the measuring instrument.
Under certain conditions the tube between combustion chamber and indicator cock works as a resonator and
produces oscillation.
Solution: Pipe oscillation filter added to the software. The filter removes oscillation from
the pressure signal. Pcomp detection and TDC positioning are working properly
when the filter is activated.
