AUDAX TOP ErP

7.1 AUDAX TOP 18  21 ErP MINIMUM INSTALLATION DISTANCES

Place of installation:

e place of installation is very important and must be estab-

lished by the system's designer or by a specically qualied

person, and must consider the technical requirements, standards

and laws in force.

• e unit must be installed outdoors only;

• It is recommended to avoid:

- positioning in basement windows

- obstacles or barriers that cause recirculation of exhaust air;

- places with aggressive atmospheres;

- limited spaces or anyhow in places where sound levels from

the appliance can be enhanced through reverberations or

resonance;

- positioning in corners where there is an accumulation of dust,

leaves and anything else that can reduce the appliance's e-

ciency due to blocked passageways;

- prevent exhaust air from the device from coming into the rooms

through doors or windows, thus disturbing people;

• e appliances must:

- be placed on a level surface that is able to withstand its weight;

- be placed on a slab that is hard enough and which does not

transfer any vibrations to the underlying or adjacent rooms;

- use the vibration-dampening supports supplied with the

machine.

• If the unit is installed in zones subject to heavy snow, it will

be necessary to raise the machine by at least 200 mm above

the normal level reached by the snow, or alternatively use the

wall-support bracket (optional).

• If deectors are present to protect the unit against strong winds,

these deectors must be studied so as to avoid obstructing the

normal air circulation.

1000

200

300

200

300

5000200

500 500500200
