AUDAX TOP 8 ErP
39
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
0 500 1000 1500 2000 2500
17.1 AUDAX TOP 8 ErP PUMP SETTINGS AND CONFIGURATIONS
Head (kPa)
17 GRAPH OF AUDAX TOP 8 ErP PUMP FLOW RATE/HEAD
Flow rate l/h
TECHNICAL NOTE: System minimum water content:
To facilitate proper execution of the AUDAX TOP ErP heat pump defrost cycles, a minimum water content in the system is required,
which must be: 6 l/kW of the machine's power for any type of system. e ywheel guarantees normal operation of AUDAX TOP ErP
with systems divided into zones (with variable water content in circulation). e ywheel also guarantees proper operation with fan coils
used for cooling (a condition in which the ow temperature is very low and has signicant heat load variations that vary the number of
active fan coils). It is also important to check that the dehumidier line has a minimum of 3 l/kW of the machine (dehumidier hydraulic
circuit connection).
N.B.: for inertial tanks codes supplied by Immergas, refer to page 107.
AUDAX TOP 8 ErP range boilers are supplied with a low power
consumption pump with variable speed control.
e circulating pump is equipped with electronic control to set
advanced functions.
Constant head (∆P C) (Ref. 4 above g.) default setting. e
circulator pump maintains the pressure level (head) constant as
the system heat demand decreases (ow rate reduction). With
these settings, the pump is suitable for all oor systems.
Proportional head (∆P V) (Ref. 3 above g.). is allows
the pressure level (head) to be proportionally reduced as the
system heat demand decreases (ow rate reduction). anks to
this function, the electric power consumption of the circulator
pump is reduced further: the energy (power) used by the pump
decreases according to the pressure level and ow rate. With
this setting, the pump guarantees optimal performance in most
heating systems, proving particularly suitable in single-pipe and
two-pipe installations.
All curves have been dened in constant pressure mode with minimum, intermediate and maximum speed.
KEY:
1 - Automatic vent mode operation
2 - Light ring to indicate the operating status
3 - Proportional head operation
4 - Constant head operation
5 - Operating mode selector switch
