AUDAX TOP 21 ErP
55
Central heating circuit
Power in CH mode with water set at 35 °C
(1)
kW 21.10
Power in CH mode with water set at 45 °C
(2)
kW 19.97
Power in CH mode with water set at 55 °C
(3)
kW 19.07
CH mode COP with water set at 35 °C
(1)
4.10
CH mode COP with water set at 45 °C
(2)
3.30
CH mode COP with water set at 55 °C
(3)
2.50
Min/max heat power with water set at 35 °C
(1)
kW 8.90/30.45
Min/max heat power with water set at 45 °C
(2)
kW 8.48 / 29.59
Min/max heat power with water set at 55 °C
(3)
kW 7.89/23.24
Flow temperature range °C 20 / 57
Outdoor temp. limits for Heating mode operation °C - 20 / 30
Cooling circuit
Power in cooling mode with water set at 18 °C
(1)
kW 25.80
Power in cooling mode with water set at 7 °C
(2)
kW 18.58
Cooling mode EER with water set at 18 °C
(1)
3.80
Cooling mode EER with water set at 7 °C
(2)
3.10
Min/max cooling capacity with water set at 18 °C
(1)
kW 11.97 / 30.67
Min/max cooling capacity with water set at 7 °C
(2)
kW 8.67/23.08
Flow temperature range °C 5 / 18
Outdoor temp. limits for Cooling mode operation °C 0 / 46
General data
System max. working pressure bar 3
Head available on the system with 2700 l/h flow rate kPa (m c.a.) 85 (8.65)
Expansion vessel capacity l 8
C.H. sound power level dB(A) 74
Appliance electric protection rating IP X4
Electric power supply V - Hz 400 - 50
Permitted voltage range V 360 - 440
Maximum power absorbed W 12400
Maximum current absorbed A 19.1
Fuse inserted A 25 - Type C
Refrigerant fluid load (R410A)* g 8000
Heat pump Weight kg 199.4
30 AUDAX TOP 21 ErP TECHNICAL DATA
THE REPORTED DATA REFERS TO THE FOLLOWING CONDITIONS (in compliance with EN 14511)
:
ROOM HEATING PHASE (°C) COOLING PHASE (°C)
Water TEMP. (F/R)
(1)
- AIR (db/wb) 35/30 - 7/6 18/23 - 35 (bs)
Water TEMP. (F/R)
(2)
- AIR (db/wb) 45/40 - 7/6 7/12 - 35 (bs)
Water TEMP. (F/R)
(3)
- AIR (db/wb) 55/47 - 7/6
* Hermetically sealed system.
