AUDAX TOP ErP and Integrated System

42 ZONE REMOTE CONTROL

It is an electronic device equipped with a back-lit display to

control and adjust the room's temperature and humidity. Con-

nection to the system Manager is on the same BUS connection

as AUDAX TOP ErP and temperature-humidity probes.

It programs the relative room heat adjustment.

It can be applied to the wall using the supplied screws and plugs.

e kit must be powered at 230 Vac.

• OPTIONAL code 3.023364

44 EXPANSION BOARD FOR ZONE MANAGEMENT

is component must be powered at 24 Vac and is mainly used

for system zone management; in particular n°1 expansion kit

must be used for each zone. e expansion kit manages pump,

mixing valve and the dehumidier of the same zone, acquiring

the room request (temperature and humidity) for a determined

zone. e following can be connected to this kit:

- the room temperature - humidity sensor;

- an ON-OFF type request contact.

Installation takes place on a DIN guide for electric components

from control board. is board is envisioned as per standard

in the 2 kits for zone systems (see the following page).

• OPTIONAL code 3.021547

43 ROOM TEMPERATURE/HUMIDITY SENSOR

It is a room temperature and humidity probe, to be applied to

the wall.

Dierently to the zone remote control kit, in this case, the set-

tings of all room parameters take place on the System Manager.

e kit must be connected directly to the expansion board for

zone management.

e kit must be powered at 24 Vac.

• OPTIONAL code 3.021524
