AUDAX TOP ErP

AUDAX TOP 6 - 8 - 12 ErP (Mono-phase)

Unit 6 kW 8 kW 12 kW

Power Supply V - ph - Hz 230 - 1 - 50

Permitted voltage range V 207 ÷ 253

Maximum power absorbed kW 2 2.7 3.85

Maximum current absorbed A 11 14.5 20.7

Supply voltage fuses

gL Type

A 16 - Type B 16 - Type B 25 - Type D

Supply voltage cable section mm

(per phase) 3 x 2.5 mm

Supply voltage cable type H07RN-F

Maximum length m 50

External pump circulation maximum

current

A 2

Use H03VV-F 5x0.75 mm² cables to connect the Control Panel

AUDAX TOP 16 - 18 - 21 ErP (ree-phase)

Unit 16 kW 18 kW 21 kW

Power Supply V - ph - Hz 400 - 3 +N - 50

Permitted voltage range V 376 ÷ 424 360 ÷ 440 360 ÷ 440

Maximum power absorbed kW 6.5 10.8 12.4

Maximum current absorbed A 11.1 16.7 19.1

Supply voltage fuses

gL Type gG Type gG Type

A 16 - Type B 25 - Type C 25 - Type C

Supply voltage cable section mm

(per phase) 5G x 4 mm

Supply voltage cable Max. section mm

(per phase) 5G x 6 mm

Supply voltage cable type H07RN-F

Maximum length m 80

External pump circulation maximum

current

A 2

Use H03VV-F 5x0.75 mm² cables to connect the Control Panel

40 ELECTRIC CONNECTION CABLES FEATURES
