Immergas MAGIS COMBO PLUS V2 Series User Manual

78
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
Parameter
ID
Description Range Default
Customised
value
A 11 Outdoor unit model
Establishes the outdoor unit model
paired with the hydronic module. If
set to OFF, only the integrated
generators are activated.
OFF - 4 - 6 - 9 9
A 12 System vent
Enables the automatic vent function.
OFF - ON ON
is function activates as soon as the
unit is powered.
A 13 Number of zones
Denes the number of zones in the
heating system
1 – 2 – 3 1
A 14
Zone 2 max tempera-
ture
Denes the maximum temperature
a c c e p t a b l e b y z o n e 2
20 ÷ 80 °C 45
A 15
Zone 3 max tempera-
ture
Denes the maximum temperature
a c c e p t a b l e b y z o n e 3
20 ÷ 80 °C 45
A 16 Zone 1 humidity sensor
Denes the type of control on zone 1
humidity
SE = Temperature - humidity
sensor
ST #V#
ST = Humidistat
RP = Remote Panel
RPH = Remote Panel with
Humidistat
A 17 Zone 2 humidity sensor
Denes the type of control on zone 2
humidity
SE = Temperature - humidity
sensor
ST #V#
ST = Humidistat
RP = Remote Panel
RPH = Remote Panel with
Humidistat
A 18
Heat generator
minimum circulator
speed
Denes the minimum operating
speed of the heat generator circulator
55 ÷ 100 % 75
A 19
Heat generator
maximum xed
circulator speed
Denes the maximum operating
speed of the heat generator circulator
55 ÷ 100 % 100
A 21
BMS communication
address
Denes the communication protocol
between the hydronic module and
the condensing unit
1 ÷ 247 11
A 22
BMS communication
setting
OFF = BMS communication protocol
on 485; use if connected to optional
Immergas devices.
OFF - 485 - UC OFF
485 = Do not use
UC = Do not use
A 23 Zone 3 humidity sensor
Denes the type of control on zone 3
humidity
SE = Temperature - humidity
sensor
ST #V#
ST = Humidistat
RP = Remote Panel
RPH = Remote Panel with
Humidistat
A 30 Dominus enabling
Allows you to enable the Dominus
remote device
OFF – ON OFF
A 31 Zone 1 room thermostat
Room thermostat / Remote panel /
Remote panel with ermostat.
is denes temperature control in
zone 1
RT = Room thermostat
RT
RP = Remote Panel
RPT = Remote panel with
ermostat
