Parameter
ID
Description Range Default
Customised
value
A 32 Zone 2 room thermostat
Room thermostat / Remote panel / Remote panel with
ermostat.
is denes temperature control in zone 2
RPT = Remote
panel with er-
mostat
RT
A 33 Zone 3 room thermostat
Room thermostat / Remote panel / Remote panel with
ermostat.
is denes temperature control in zone 3
RT = Room
thermostat
RT
RP = Remote
Panel
RPT = Remote
panel with er-
mostat
A 41
Zone 1 heating / cooling
enable
Allows to determine heating, cooling mode or both of
zone 1
HT / CL / H – C H - C
A 42
Zone 2 heating / cooling
enable
Allows to determine heating, cooling mode or both of
zone 2
HT / CL / H – C H - C
A 43
Zone 3 heating / cooling
enable
Allows to determine heating, cooling mode or both of
zone 3
HT / CL / H – C H - C
Parameter
ID
Description Range Default
Customised
value
P 00 DHW max
Denes the maximum heat output percentage of
the heat generator during the D.H.W. phase
compared to the maximum heat output available
0 - 100 % 100 %
P 01 Min C.H.
Denes the minimum heat output percentage of
the heat generator during the C.H. phase com-
pared to the maximum heat output available
0 – P 02 % 0
P 02 Central heating max
Denes the minimum heat output percentage of
the heat generator during the C.H. phase com-
pared to the maximum heat output available
0 - 100 % 85 %
P 03 Relay 1 (optional)
 e h y d r o n i c m o d u l e i s s e t u p t o o p e r a t e w i t h a
congurable relay board (optional)
0 ÷ 5 0
0 = O
1 = DHW recirculation
2 =General alarm
3 = Central heating / cooling mode active
4 = Puer mode active
5 = Dehumidier zone 3
P 04 Relay 2 (optional)
 e h y d r o n i c m o d u l e i s s e t u p t o o p e r a t e w i t h a
congurable relay board (optional)
0 ÷ 5 0
0 = O
1 = DHW recirculation
2 =General alarm
3 = Central heating / cooling mode active
4 = Puer mode active
5 = Zone 3 mixing valve closing
