Immergas MAGIS COMBO PLUS V2 Series User Manual

80
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
Parameter
ID
Description Range Default
Customised
value
P 05 Relay 3 (optional)
 e h y d r o n i c m o d u l e i s s e t u p t o o p e r a t e w i t h a
congurable relay board (optional)
0 ÷ 5 0
0 = O
1 = DHW recirculation
2 =General alarm
3 = Central heating / cooling mode active
4 = Puer mode active
5 = Zone 3 mixing valve opening
P 07 External probe correction
If the reading of the external probe is not accurate,
i t i s p o s s i b l e t o c o r r e c t i t i n o r d e r t o c o m p e n s a t e
any environmental factors
-9 ÷ 9 K 0
P 11
Gen. thermal DHW setpoint
oset
e DHW ow setpoint of the thermal generator is
c a l c u l a t e d b y a d d i n g P 0 11 t o t h e D H W s e t p o i n t
2 ÷ 30 °C 20
P 12
DHW electric resistance
tripping oset
Call Immergas technical service assistance 5 ÷ 50 °C 10
P 13 T max anti-Legionella
Maximum time to perform anti-Legionella
function
1 - 24 hours 3
P 14 T max DHW Maximum time to perform DHW function 1 - 24 hours 5
P 15 Anti-Legionella function enable Enable running of anti-Legionella function OFF - ON OFF
P 16
Anti-legionella function start
time
Allows to set when anti-Legionella function starts 0 - 23 2
P 17
Day of the week to start the
antilegionella function
Allows to set the weekday on which to activate the
anti-Legionella function. You may even activate
the function continuously every day
Mo-Tu-We-
- Fr-Sa-Su
P 21 Activation time Temperature setpoint - Activation time correction 0 - 120 minutes 20
P 22 Activation time Temperature setpoint - Increment time correction 0 - 20 minutes 5
P 23 Heat setpoint correction
Allows to correct the heating mode demand
s e t p o i n t i n p r e s e n c e o f d i s p e r s i o n s o r s y s t e m
decoupling circuits
0 ÷ 10°C 0
P 24 Cool setpoint correction
Allows to correct the cooling mode demand
s e t p o i n t i n p r e s e n c e o f d i s p e r s i o n s o r s y s t e m
decoupling circuits
0 ÷ 10°C 0
Parameter
ID
Description Range Default
Customised
value
T 02 D.H.W. thermostat
is establishes the ignition and shutdown mode
of the appliance in DHW mode.
It is enabled when the water in the storage tank
goes below the DHW set value and is disabled
when the temperature exceeds the DHW set value
0 ÷ 20 °C 4
T 05 Central heating ignitions timer
 e h y d r o n i c m o d u l e h a s a n e l e c t r o n i c t i m e r,
which prevents the generator from igniting too
oen in central heating mode
0 - 10 minutes 3
T 06 Heating ramp timing
In the heating stage, the heat generator performs
an ignition ramp in order to reach the maximum
output set
0 - 14 minutes 14
