81
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
Parameter
ID
Description Range Default
Customised
value
T 07 Delay request from TA
 e s y s t e m i s s e t t o s w i t c h o n i m m e d i a t e l y a  e r a
request for room air conditioning. For special
systems (e.g. zone systems with motorised valves,
etc.), it may be necessary to delay ignition.
0 - 240 seconds
(10 sec step)
0
T 08 Display lighting
Establishes the display lighting mode.
AU: the display lights up during use and dims aer
15 seconds of inactivity, in case of anomaly the
display works in ashing mode.
OFF: display lighting is always o.
ON: display lighting is always on.
AU - OFF - ON AU
T 09 Display
Establishes what the indicator displays 14 (Fig. 12).
“Summer” mode:
ON: active circulator, this displays the ow
t e m p e r a t u r e , w i t h c i r c u l a t o r o  t h e i n d i c a t o r i s o 
OFF: the indicator is always o
“Winter” and “cooling” mode:
ON: active circulator, this displays the ow
temperature, with circulator o the set value is
displayed on the central heating selector
OFF: this always displays the value set on the
central heating selector
ON - OFF ON
T11 Do not use 0 ÷ 36 0
T 21
Screed heating - days at
minimum temperature
Denes the time spent at minimum operating
temperature during the active function
0 ÷ 7 days 3
T 22 Screed heating - ascent gradient Denes the ascent gradient of the temperature 0 - 30°C / day 30
T 23
Screed heating - days at
maximum temperature
Denes the time spent at maximum operating
temperature during the active function
0 ÷ 14 days 4
T 24
Screed heating - descent
gradient
Denes the descent gradient of the temperature 0 - 30°C / day 30
Heat regulation menu.
Parameter
ID
Description Range Default
Customised
value
R 01 External probe
Denes if and which external probe is used to
manage the system. OFF = no external probe is
used
OU = external probe on the condensing unit
IU = optional external probe connected to the
hydronic module
OFF - OU - IU OU
R 02
Outdoor temperature for max
CH ow zone 1
Establishes the outdoor temperature at which to
have the maximum ow temperature of zone 1.
-15 ÷ 25 °C -5
R 03
Outdoor temperature for min
CH ow zone 1
Establishes the outdoor temperature at which to
have the minimum ow temperature of zone 1.
-15 ÷ 25 °C 25
R 04
Zone 1 maximum central
heating
Denes the maximum ow temperature in zone 1
room central heating mode
20 ÷ 80 40
R 05
Zone 1 minimum central
heating
Denes the minimum ow temperature in zone 1
room central heating mode
20 ÷ 80 25
