83
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
Integration menu.
Parameter
ID
Description Range Default
Customised
value
I 01 DHW integration enabling
Allows you to enable an alternative power source
(AL) to integrate domestic hot water heating
OFF - AL AL
I 02 System integration enabling
Using this function, you can enable an alternative
(AL) power source to integrate heating system
central heating
OFF - AL AL
I 03 DHW max wait time
Establishes the maximum amount of time before
activating DHW integration
1 - 255 minutes 15
I 04 Central heating max wait time
Establishes the maximum amount of time before
activating central heating integration
1 - 255 minutes 30
I 05 Integration activation mode
Establishes how to integrate the heat generator to
the outdoor unit, you can choose between “AU”
automatic and “MA” manual
AU - M A AU
I 06 Activation temperature
Establishes the outdoor temperature under which
central heating integration is enabled
-15 ÷ 35 °C -5
I 07 Activation band
Establishes a temperature range around the
calculated temperature to determine which
generator to switch on
0 ÷ 10 °C 4
I 08 Simultaneous D.H.W.
Enables the simultaneous operation in DHW
mode and room air conditioning mode
OFF - ON ON
I 11 Outdoor unit operating hours
Displays the hours of operation performed by the
outdoor unit
I 12
Indoor central heating unit
hours of operation
Displays the hours of operation by the indoor
central heating unit
I 13
Indoor D.H.W. unit hours of
operation
Displays the hours of operation by the indoor unit
in DHW
Maintenance menu.
Accessing this menu, the unit goes into stand-by. By selecting
every single parameter, you can activate a specic function for
each load.
Parameter
ID
Description Range Default
Customised
value
M 02
Heat pump circuit circulator
speed
Establishes the circulator speed linked to the heat
pump circuit
0 - 100% 0
M 03 Heat generator 3-way circuit Moves the 3-way motor from system to DHW
DHW-CH-
MD
DHW
M 04 Cooling 3-way Moves the cooling circuit 3-way motor OFF - ON OFF
M 06
Heat generator circuit circulator
speed
Establishes the circulator speed linked to the heat
generator
0 - 100% 0
M 07 Heat pump three-way circuit Moves the 3-way motor from system to DHW OFF - ON OFF
M 08 Zone 1 outdoor circulator pump Enables the zone 1 outdoor circulator pump OFF - ON OFF
M 09 Zone 2 outdoor circulator pump Enables the zone 2 outdoor circulator pump OFF - ON OFF
M 10 Mixer zone 2 Establishes zone 2 mixing valve positioning
OFF - OPEN
- CLOSE
OFF
M 11 DHW electrical resistance Enables the DHW integrated electrical resistance OFF - ON OFF
