Chapter 5 General Reference 109
FREQUENCY ITEM KEY INSPECTION DESCRIPTION STATUS
(S,R,X,NA)
82
• Main control valve
83
• Load holding valve(s)
84
• Stabilizer or auxiliary control valve(s)
85
• Other
86
• Other
Q
87
Cylinders
Hydraulic cylinders for drifting, rod seal leakage and leakage at welds.
Rods for nicks, scores and dents. Case for damage. Case and rod
ends for damage and abnormal wear.
88
• Stabilizer cylinder(s)
89
• Inner boom cylinder(s)
90
• Outer boom cylinder(s)
91
• Extension cylinder(s)
92
• Rotation cylinder(s)
93
• Jib lift cylinder(s)
94
• Jib extension cylinder(s)
95
• Other
Q
96
Winch
Winch, sheaves and drums for damage, abnormal wear, abrasions
and other irregularities.
Q
97
Hyd Filters
Hydraulic filters for replacement per maintenance schedule.
A
98
Daily
All daily inspection items.
A
99
Monthly
All monthly inspection items.
A
100
Quarterly
All quarterly inspection items.
A
101
Hyd Sys
Hydraulic fluid change per maintenance schedule.
A
102
Controls
Control valve calibration for correct pressure & relief valve settings.
A
103
Valves
Safety valve calibration for correct pressure & relief valve settings.
A
104
Valves
Valves for failure to maintain correct settings.
A
105
Rotation Sys
Rotation drive system for proper backlash clearance & abnormal wear,
deformation and cracks.
A
106
Lubrication
Gear oil change in rotation drive system per maintenance schedule.
A
107
Hardware
Check tightness of all fasteners and bolts, using torque specifications
on component drawings or torque chart.
A
108
Wear Pads
Wear pads for excessive wear.
A
109
Loadline
Loadline for proper attachment to drum.
