IMT 5525

Contents iii
Revisions
DATE LOCATION DESCRIPTION
20070501
Manual Release
20070524
Added parts for 70570771 winch into manual for reference only. Winch
was changed 6-1-07.
20070621
ECN 10514 - Added 71410928 cylinder assembly. Added serial
number information on winch and valves.
20070716
Added 99904248 flip sheave assembly.
20070718
73734193
ECN 9000 - CORRECTED, ADDED PARTS.
20071019
Added telescopic crane orientation drawing, cable note to 41719740.
20071115
99904035
ECN 10625 - Changes to drawing with production quantities of
71570825 winch.
20080204
51719015,
51719074,
51719075
ECN 10628 - UPDATED CYLINDER PORT TUBE DRAWINGS PER
ASSEMBLY
20080422
99904235
ECN 10723 - HARDWARE KIT CHANGES.
20080515
93719174
ECN 10758 - NEW LEVEL INDICATOR & NOTE.
20080929
99903945
ECN 10820-1- MOTOR CHANGE FROM 73511070 TO 73051919
71570825
DUAL COUNTERBALANCE VALVE PART NUMBER 73540344
ADDED.
20081022
99904248
ECN 9000 - CABLE ASSEMBLY 70580168 WAS 70580143.
20090403
99904036,
71570825
UPDATED VIEWS ON 99904036. ADDED SPARE PARTS ON
71570825.
20100503
99903945,
99903943,
73734472,
99904783
ECN 11134 - TELESCOPIC VALVE UPGRADE
20110204
71570825
ADDED 71570825 WINCH INSERT #9, ADDED REPLACEMENT
VALVE COIL INFORMATION.
20111101
99904036
ECN 11567 - CHANGE TO HYD KIT
20120423
51718994,
51719015A,
51719074A,
51719075A,
3B205010
ECN 11615 - CYLINDER CHANGES. ADDED PROP REMOTE
CALIBRATION PROCEDURE.
20130613
70570771
70570771
Per engineering mark-up; item 44 typo corrected.
Added item 23 part number.
20131205
99904235
ECN 12027; Item 2 part number change.
20140304
51718994
Added Note 7, item 18
20140508
71570825
Corrected/Added part numbers per 9/11 drawing from vendor.
