IMT 5525 Parts & Specifications

Chapter 4 Parts 29
5 MAST ASSEMBLY SHOWN AS ASSEMBLED ON ASSEMBLY STAND. NOTE LOCATION OF HYDRAULIC
ROTATION MOTOR.
6 TORQUE TO 280 FT-LB
7 USE BLUE THREAD LOCKER.
99903945 PARTS LIST
ITEM
PART #
DESCRIPTION
QUANTITY
1.
99903898
HYD INSTALLATION DRAWING
REF
2.
51720118
HARDWARE KIT-BASE & MAST(INCL 14-25, 33)
1
3.
91720393
HOSE KIT-PLANETARY WINCH(INCL 29-31)
(INCL 91720110)
1
4.
52720018
MAST WELDMNT
1
5.
71056577
GEAR ROTATOR-6025/6625 0.75 BOLTS
1
6.
77441204
HARNESS - TELE RADIO REMOTE (WAS
77441184 THROUGH 8-1-06)
1
7.
60128848
INDICATOR-MAST LOCATION
1
8.
60128849
GEAR GUARD
1
9.
60120138
SLIDE-ROTATION STOP 3816
1
10.
60350119
TAPE-GREEN REFLECTIVE 2.00X 17.40
REF
11.
60350120
TAPE-YELLOW REFLECTIVE 2.00X 9.46
REF
12.
60350121
TAPE-YELLOW REFLECTIVE 2.00 X 3.24
REF
13.
60350122
TAPE-RED REFLECTIVE 2.00X 14.14
REF
14.
70029595
THREADED PLUG 1.00-8 (3816)
2
15.
70034060
TIES-PLASTIC .18W 8.00L BLACK
5
16.
70034382
CAP-GREASE
3
17.
72053301
COUPLING-BLK .12
1
18.
72053508
ZERK-NPT .12
1
19.
72060004
CAP SCR .25-20X 1.00 HH GR5 Z
4
20.
72060794
CAP SCR .50-13X 1.25 SH PLAIN
2
21.
72062104
NUT .25-20 HEX NYLOCK
4
22.
72063001
WASHER .25 FLAT
8
23.
72063116
WASHER .75 N FLAT H ASTMF436Z
22
24.
72601629
CAP SCR .75-10X 4.00 HH GR8 Z
4
25.
72601817
CAP SCR .75-10X 3.25 HH GR8 Z
16
26.
73051919
MOTOR-HYDRAULIC (WAS 73511070)
1
27.
76039295
GASKET-GEA19 008-10056-1
1
28.
51395121
HOSE-AA .13 X 13.50 OAL (2-2)
1
29.
72533613
ADPTR-M STR/M JIC 10 6
2
30.
72053758
ELBOW-M STR/90/M JIC 4 4
2
31.
72532357
ADPTR-M STR/M JIC 6 8
1
32.
73734472
VALVE BANK-MOD.INLET (PW) (73734193
FROM 6025S2071211 TO 6025S2091069)
(WAS 51720111 THRU 5-4-07)
1
33.
72060207
CAP SCR .75-10X 3.00 HH GR8 Z
2
REV F 20100503
