IMT 5525 Parts & Specifications

36 Model 5525-6025-6625 Parts & Specifications Manual Part # 99904215
51719015 PARTS LIST
ITEM
PART #
DESCRIPTION
DETAILS
KIT #
QUANTITY
13.
76396608
BACKUP RING
2.02 ID X 2.26 OD
#1
2
14.
7Q072226
O RING
2.00X 2.25X .12 70
#1
1
15.
7Q072350
O RING
4.62X 5.00X .19 70
#1
1
16.
7Q10P350
BACKUP RING
4.62 ID X 5.00 OD
#1
1
17.
7R14P025
ROD WIPER
TYPE D 2.25 ROD
#1
1
18.
7T2NX427
WEAR RING-ROD
2.50 ID X 0.50W HAL
#1
2
19.
7T66P500
PISTON SEAL-DYNAMIC
5.00" CP
#1
1
20.
70055225
BEARING
GAR DX 2.00X2.19X2.00
#2 & #3
4
21.
73540094
VALVE-DUAL CNTRL
PRESS SWITCH
1
22.
72533186
ADAPTER
M FACE/M STR 6 6
4
23.
70145753
TUBE ASM-2015 LOWER
CYL FACE
1
24.
70145927
TUBE ASM - 5020
LOWER CYL FACE
1
25.
73540052
VALVE-CBAL
1.75:1 3300 PSI ADJ
1
26.
77041625
SWITCH-PRESS
3100PSI -6 NC SHROUD 48 IN
1
27.
77041626
SWITCH-PRESS
3500PSI -6 NC TOWER 30in
1
28.
72063002
WASHER
.31 FLAT
4
29.
72060037
CAP SCREW
.31-18X 4.00 HH GR5 Z
2
30.
72062109
NUT
.31-18 HEX NYLOCK
2
REV C 20120523

IMT 5525 Specifications
