42 Model 5525-6025-6625 Parts & Specifications Manual Part # 99904215
99904235 PARTS LIST
ITEM
PART #
DESCRIPTION
KIT #
QUANTITY
1.
51720032
KIT-HRDW BOOM ASY 6025 Sll
1
2.
52725232
TUBE WELDMENT- ANTI TWO BLOCK
1
3.
52718672
BOOM-1st STAGE EXT WLDMT
1
4.
52718673
BOOM-2nd STAGE EXT WLDMT
1
5.
52720321
BOOM-LOWER WLDMT 6025SII
1
6.
60030336
WEAR PAD-RC .19 X 6.00 X 6.00
2
7.
60030337
WEAR PAD-RND 2.00 DIA X 1.00 DIA X 1.188 LG
4
8.
60105544
PLATE-ANGLE PLASTIC
2
9.
60122358
PLATE-SINGLE SHEAVE (12#) 6020
1
10.
60122984
WEAR PAD-RND 6625 CYLINDER
1
11.
60122985
WEAR PAD-RND 6625 BOOMS
4
12.
60122986
PIN-TYPE A 1.25X 7.00 ( 6.31)
1
13.
70396734
DECAL-BOOM LENGTH INDICATOR
4
14.
60126259
RETAINER-1st STAGE EXT CYL
2
15.
70034381
SUPPORT-GP STAUFF LN-4190-PA
#1
3
16.
70034382
CAP-GREASE PRO20 GC-RED
#1
2
17.
70146096
SPRING 0.62 X 2.50 X 14 GA.
#1
2
18.
70396121
CAP-PLSTC 1.00 TUBE OD X 0.68 HGT BLACK
(EFFECTIVE TO 07/18/13)
#1
2
19.
72053508
ZERK-NPT .12
#1
2
20.
72060007
CAP SCR .25-20X 1.75 HH GR5 Z
#1
3
21.
72060055
CAP SCR .38-16X 3.50 HH GR5 Z
#1
2
22.
72060098
CAP SCR .50-13X 3.50 HH GR5 Z
#1
1
23.
72062080
NUT .50-13 HEX NYLOCK
#1
1
24.
72062103
NUT .38-16 HEX NYLOCK
#1
4
25.
72062179
NUT .38-16 HEX CENTER LOCKING
#1
2
26.
72063001
WASHER .25 FLAT
#1
2
27.
72063003
WASHER .38 FLAT
#1
10
28.
72063005
WASHER .50 FLAT
#1
6
29.
72063035
MACHY BUSHING 1.25X10 GA NR
#1
2
30.
72063049
WASHER .25 LOCK
#1
5
31.
72063116
WASHER .75 N FLAT H ASTMF436Z
#1
1
32.
72063117
WASHER .56 FLAT ASTM F436
#1
4
33.
72066145
HAIR PIN .19 ZINC
#1
1
34.
72601484
CAP SCR .75-10X 1.75 HH GR8 Z
#1
1
35.
72661312
CLAMP- .50 LOOP CUSHIONED
#1
1
36.
77041459
SWITCH-LIMIT ZE-N-2S
1
37.
51721028
CYL ASM-2.50/1.75 2.75/1.75 150.0 126.13
1
38.
72066129
RETAINING RING-EXT 1.25 HD
#1
2
39.
72661514
PIN-LOCK W/HANDLE .875 X 4.25
#1
1
40.
72661543
PIN-QUICK 316-10QP
#1
1
41.
60122983
WEAR PAD-RC ERTALYTE-TX .50X5.00X6.00
1
42.
51720302
CORD REEL ASM- 10' W/PACKARD CONNECTOR
1
43.
72034485
CLAMP-PLASTIC 1/4" CABLE
#1
5
44.
72062106
NUT 10-24 HEX NYLOCK
#1
5
45.
72060000
CAP SCR .25-20X .50 HH GR5 Z
#1
2
